MAX3232 SOP16
The MAX3232 device consists of two line drivers, two line receivers, and a dual charge-pump circuit with ±15-kV ESD protection terminal to terminal (serial-port connection terminals, including GND). The device meets the requirements of TIA/EIA-232-F and provides the electrical interface between an asynchronous communication controller and the serial-port connector. The charge pump and four small external capacitors allow operation from a single 3-V to 5.5-V supply. The devices operate at data signaling rates up to 250 kbit/s and a maximum of 30-V/µs driver output slew rate
DATASHEET: http://www.ti.com/lit/ds/symlink/max3232.pdf
RS-232 Bus-Terminal ESD Protection Exceeds
±15 kV Using Human-Body Model (HBM)
Meets or Exceeds the Requirements of TIA/EIA-232-F and ITU V.28 Standards
Operates With 3-V to 5.5-V VCC Supply
Operates up to 250 kbit/s
Two Drivers and Two Receivers
Low Supply Current: 300 µA Typical
External Capacitors: 4 × 0.1 µF
Accepts 5-V Logic Input With 3.3-V Supply
Alternative High-Speed Terminal-Compatible Devices (1 Mbit/s)
SN65C3232 (–40°C to 85°C)
SN75C3232 (0°C to 70°C)
- MAX3232 SOP16
